Hydraulic Flatbed Tipper Trailer with Ramps - 12x7 (3.6m x 2.1m) 3500kg
Type: G
SKU: FHE127
From $10,900
Availability: Available
Irontow Flatbed Tipper Trailers are versatile, durable, and fully hot dip galvanised for long-term protection against rusting.
The Irontow 12x7 Flatbed Hydraulic Tipper Trailer includes slide out ramps and stabilising legs and is perfect for transporting heavy duty and/or oversized materials and equipment including Construction and Building Materials, Scrap metals and Landscaping materials. The Hydraulic Tipping feature makes unloading a breeze!
- 3500kg ATM
- All Electric Brakes
- Fully Hot Dip Galvanised
Any questions please ring us on 0408 999 920 or visit our site on 3/5 Caravan St Wendouree VIC 3355
Features
| Ramps | Built in ramps storage, slide out ramps |
|---|---|
| Tyres | 4 x Brand new 215/70R15 light truck tyres |
| Coat | Fully Hot Dip Galvanised |
| Safety | Brake-away system |
| Suspension | Rocker Roller Suspension |
| Coupling | Australian Standard |
| Plug | 7 pin Flat |
| Lights | LED |
| Jockey wheel | Swing up 10 inch heavy duty |
| Warranty | 12 month |
| Hydraulic Ram | 5 stage 5 ton hydraulic ram |
Specifications
| ATM | 3500kg |
|---|---|
| Tare | 1490kg |
| Overall Length | 5.23m |
| Outer Width | 2.13m |
| Inner Length | 3.56m |
| Inner Width | 2.01m |
| Floor Height | 0.92m |
| Drawbar | 100x50x5mm 1600mm |
| Upper Chassis | 100x50x4mm |
| Lower Chassis | 100x50x5mm |
| Cross Bar | 70x50x3mm |
| Sides | 300mm removable |
| Spring | 60x8mm 7 leafs |
| Axle | 50x50mm solid square |
| Brake | 10-inch electric |
| Tyre | 217/70R15 LT |
| Wheel Hub | 6-139.7 Landcruiser Pattern |
| Ram | 5 stage 5 ton ram |
| SKU | Registration | Spare Tyre | Cage | Availability | |
|---|---|---|---|---|---|
 | FHE127 | N/A | N/A | N/A | Available |
 | FHE127-R | VIC Roads | N/A | N/A | Available |
 | FHE127-T | N/A | Light Truck | N/A | Available |
 | FHE127-C2 | N/A | N/A | 12x7x2 Cage | Available |
 | FHE127-T-C2 | N/A | Light Truck | 12x7x2 Cage | Available |
 | FHE127-R-T | VIC Roads | Light Truck | N/A | Available |
 | FHE127-R-C2 | VIC Roads | N/A | 12x7x2 Cage | Available |
 | FHE127R-T-C2 | VIC Roads | Light Truck | 12x7x2 Cage | Available |
